imageobject

imageobject — A wrapper for image data and its associated meta-information.

Synopsis

imageobject ::=

Sequence of:
- info? (db.titleforbidden.info)
- One of:
  - One or more of:
    - imagedata (db.imagedata)
  - One or more of:
    - imagedata (db.imagedata.svg)
  - imagedata (db.imagedata.mathml)

Attributes

Common attributes and common linking attributes.

No additional attributes.

Description

An imageobject is a wrapper containing imagedata and its associated meta-information.

If the SVG Module is used, imageobject can also contain the svg:svg element.

Processing expectations

May be formatted inline or as a displayed block, depending on context. It might not be rendered at all, depending on its placement within a mediaobject or inlinemediaobject and the constraints on the publishing system. For a more detailed description of the semantics involved, see mediaobject.

Attributes

Common attributes and common linking attributes.

any attribute: Any attribute in any other explicit namespace

Parents

These elements contain imageobject: imageobjectco, inlinemediaobject, mediaobject.

Children

The following elements occur in imageobject: imagedata (db.imagedata), imagedata (db.imagedata.mathml), imagedata (db.imagedata.svg), info (db.titleforbidden.info).

Examples

 1 |<article xmlns='http://docbook.org/ns/docbook'>
   |<title>Example imageobject</title>
   |
   |<mediaobject>
 5 |  <imageobject condition="web">
   |    <imagedata fileref="figs/web/db5d_ref09.png" format="PNG" scale="70"/>
   |  </imageobject>
   |  <imageobject condition="print">
   |    <imagedata fileref="figs/print/db5d_ref09.pdf" format="PDF"/>
10 |  </imageobject>
   |  <textobject>
   |    <phrase>The Eiffel Tower</phrase>
   |  </textobject>
   |  <caption>
15 |    <para>Designed by Gustave Eiffel in 1889, The Eiffel Tower is one
   |          of the most widely recognized buildings in the world.
   |    </para>
   |  </caption>
   |</mediaobject>
20 |
   |</article>
