Formatted as a displayed block.

Common attributes and common linking attributes.

any attribute

Any attribute in any other explicit namespace

floatstyle

Specifies style information to be used when rendering the float

label

Specifies an identifying string for presentation purposes

pgwide

Indicates if the element is rendered across the column or the page

Enumerated values:
“0”	The element should be rendered in the current text flow (with the flow column width).
“1”	The element should be rendered across the full text page.

type

Identifies the type of figure

These elements contain informalfigure: abstract, acknowledgements, annotation, answer, appendix, article, bibliodiv, bibliography, bibliolist, blockquote, callout, calloutlist, caption (db.caption), caution, chapter, colophon, constraintdef, cover, danger, dedication, entry, example, figure, footnote, glossary, glossdef, glossdiv, glosslist, important, index, indexdiv, informalexample, informalfigure, itemizedlist, legalnotice, listitem, meta (db.meta.content), msgexplan, msgtext, note, orderedlist, para, partintro, preface, procedure, qandadiv, qandaset, question, refsect1, refsect2, refsect3, refsection, refsynopsisdiv, result, revdescription, sect1, sect2, sect3, sect4, sect5, section, setindex, sidebar, simplesect, step, taskprerequisites, taskrelated, tasksummary, td, textobject, th, tip, toc, tocdiv, topic, variablelist, warning.

The following elements occur in informalfigure: address, anchor, annotation, bibliolist, blockquote, bridgehead, calloutlist, caption (db.caption), caution, classsynopsis, cmdsynopsis, constraintdef, constructorsynopsis, danger, destructorsynopsis, enumsynopsis, epigraph, equation, example, fieldsynopsis, figure, formalgroup, formalpara, funcsynopsis, glosslist, important, indexterm (db.indexterm.endofrange), indexterm (db.indexterm.singular), indexterm (db.indexterm.startofrange), info (db.titleforbidden.info), informalequation, informalexample, informalfigure, informaltable (db.cals.informaltable), informaltable (db.html.informaltable), itemizedlist, literallayout, macrosynopsis, mediaobject, methodsynopsis, msgset, note, orderedlist, packagesynopsis, para, procedure, productionset, programlisting, programlistingco, qandaset, remark, revhistory, screen, screenco, screenshot, segmentedlist, sidebar, simpara, simplelist, synopsis, table (db.cals.table), table (db.html.table), task, tip, typedefsynopsis, unionsynopsis, variablelist, warning.
